Consigned PCB Assembly

Consigned PCB Assembly is a win-win solution with parts supplied by the customer and manufacturer’s expertise!

While many clients prefer to go the turnkey assembly route where component sourcing, manufacturing and assembly is the responsibility of the Contract Manufacturer, Consigned PCB Assembly is growing as a popular option. It essentially involves the customer supplying all the parts and components required for the circuit boards, while the fabrication and assembly is seamlessly handled.

In addition, there can also be a hybrid solution with a partial consigned PCB Assembly, where the customer supplies some parts and the contract manufacturer supplies the rest. You may want to provide some special components while wanting the contract manufacturer to take care of the rest. Whether you opt for fully consigned PCB Assembly or a partial one, the contract manufacturer will be responsible for the quality of PCBA.

At Technotronix, we are fully equipped to offer both full Turnkey as well as full consigned and partial consigned printed circuit board assembly. In each case we offer custom PCB Assembly to meet your stringent requirements.

Consigned PCB Assembly Capabilities

Our consigned PCB assembly capabilities span the following:

  • RoHS 5 & RoHS 6 compliant PCB Assembly
  • Plated-through hole, Surface Mount as well Mixed Technologies.
  • Leaded as well as lead free assemblies
  • Quick turnaround times
  • Custom testing and DFM checking
  • High level of customer support

Essentially, we carry out the processes detailed below in a secured environment to ensure high quality PCB Assembly. The broad steps include:

  • Accurate addition of solder paste with a solder screen
  • Picking and placing components on the boards
  • Soldering
  • Thorough inspection to detect any wrong or misplaced components.

In addition, When you choose Technotronix, you also benefit from our highly competitive rates that will minimize your overall cost of production.

Consigned PCB Assemblies

Benefits of Consigned Printed Circuit Board Assembly

Consigned PCB Assembly works best where customers already have their own components or if they manufacture proprietary products. Conversely, if you have a large backlog of components, Consigned Printed Circuit Board Assembly is beneficial.

Essentially consigned assembly helps customers to redistribute the work while keeping their own manufacturing facility. It is also preferred when the customer manufactures expensive products with parts that are exclusive. In such cases the customer also reaps the advantage that the product isn’t replicated and also retains a significant cost advantage.

Also, in this approach the customer has full control over material as also packaging and shipping of material before it is handed over for final assembly. In such cases they benefit from a contract manufacturer that works closely with their in-house supply chain. This helps both quick PCB Assembly as well as quick time to market.

Some of the other benefits of Consigned PCB Assembly include:

  • Stringent control on quality
  • Reduced manufacturing cost
  • Reduced turnover times

Application of Consigned PCB Assembly

Consigned Assembly finds extensive application in cases where:

  • The customer already has access to components.
  • The parts manufactured by the customer are proprietary and/or expensive.
  • It ensures that there is more customer control in terms of the correct material and to see that everything is in order before it is passed on for manufacturing.
  • This works as an added security step especially for applications which are complex in terms of assembly.

Technotronix Advantage

At Technotronix we have over 4 decades of experience in fabricating and assembling PCBs. We deal with a wide variety of PCBs irrespective of their complexity levels. This is made possible on account of our state-of-the-art equipment as well as a well-qualified and experienced team. The fact that we have a huge body of industry best practices available with us to ensure that you would not need to reinvent the wheel.

Particularly for Consigned PCB Assembly, we are known to offer:

  • Quick turnaround times
  • Reduced human intervention and errors with our automated machinery.
  • Stringent quality control by way of tests and inspections such as ICT, X Ray inspection, Automated Optical Inspection and more.
  • Cost effective solutions.

You can also rest assured that you will be offered the highest degree of customer support.

All you need to do is to get in touch with our team and share your specific requirements. Our team will share a custom quote and ensure that the PCB is assembled to your exact needs.

Consigned PCB Assembly FAQs

Simply put, it refers to a solution where the customer supplies all the parts and components required for the circuit boards, while the fabrication and assembly is seamlessly handled by the contract manufacturer.

Yes a hybrid version refers to a partial consigned PCB Assembly, where the customer supplies some parts and the contract manufacturer supplies the rest.

It is known to work well where the customer manufacturers proprietary products or where they have a large backlog of components. It also offers customers an increased degree of control.

We offer stringent quality control by way of tests and inspections such as ICT, X Ray inspection, Automated Optical Inspection and more.

Absolutely. You can count on us to offer you RoHS 5 &RoHS 6 compliant PCB Assembly.

Absolutely. Not just for consigned PCB Assembly, we are well known for quick turnaround times for all our PCBs

You can count on us when we say our customer support process is extremely robust. You can expect quick responses and handholding.

We have over 4 decades of experience in dealing with different varieties of printed circuit boards, turnkey PCB assembly and more.

Without a doubt! You can rest assured that the PCBs will be assembled to your bespoke requirements.

Above everything, a large portfolio of satisfied clients stands as the biggest testimony to our success.
contact icon

You can use PCB Assembly quote request form to inquire about consigned assembly and submit information. Alternatively, you can email us BOM and Gerber files along with information of full turnkey PCB assembly or consigned PCB assembly, PCB assembly volume, type of PCB Assembly and testing requirements on sales@technotronix.us or call us on 714/630-9200 in case any other clarification is required in respect to our PCB Assembly Capabilities.
