Rapid Printed Circuit Board Prototype

Rapid printed circuit board prototype is the perfect way to save costs and valuable time! We have state-of-art facility to manufacture rapid printed circuit boards prototypes in California, USA. While it may sound simpler to place an order for a full rapid PCB prototyping production run, the fact is that any mistake discovered at a later stage can prove to be extremely costly. This is the exact reason why rapid PCB prototypes have gained the importance that they have. These boards allow you to ensure you have the right designs. With a PCB prototype you can test it and then get to the production stage.

What really is rapid PCB prototyping? Simply put, it refers to the quick fabrication of a PCB board often using 3D computer aided design. The fabrication is usually completed using additive manufacturing, or what is more commonly known as 3D printing. It is ideal for complex projects that are under tight deadlines, as it allows for any flaws to be identified early.

At Technotronix, we offer rapid printed circuit board prototype that adhere to your design specifications and help you get started on your standard production run!

Capabilities of Rapid printed circuit board prototype

Our capabilities in rapid PCB prototyping span the entire gamut of rigid, flex and rigid-flex prototypes. In short, we ensure that quantity doesn’t come in the way of quality.

Here’s an overview of our capabilities for each PCB rapid prototyping:

Capabilities of Rapid printed circuit board prototype
Features Capabilities
Rigid PCBs Up to 24 layers
Panel Size up to 21ʺx26ʺ
Metal core or metal backed
A wide range of laminates
Copper thickness – 8 Oz. inner layer/16 Oz. outer layer
Rigid Flex PCBs 24+ layers
A wide range of custom finishes
Metal core or metal backed
UL qualified
Flexible PCBs Up to 20 layers
Board size up to 20ʺ x 24 ʺ
Board thickness: 0.1mm – 0.8mm
Blind and buried vias
RoHS compliant

Benefits of Printed Circuit Board Rapid Prototyping

Rapid PCB prototyping offer a wide variety of benefits such as:

  • Ability to correct designs at an early stage.
  • Mitigate risk and save money.
  • Benefit from lower production tolerance.
  • Prototypes can accommodate more layers.
  • It is useful for testing functions of individual components as well as complex devices. Provides opportunity to iterate and innovate.
  • Improves quality of final product.
  • Great for investor pitches.

Application of Rapid Printed Circuit Board Prototype

Rapid prototype printed circuit boards find wide application in a variety of industries especially those dealing with complex devices. In mission critical industries where there is no leeway of any error, PCB prototypes are particularly useful. Some of these industries include:

Rapid PCB Prototyping

Military & Defense

Rapid PCB Prototype

Medical

Rapid Prototype PCB

Electronics

Rapid Prototyping PCB

Robotics

PCB Rapid Prototyping

Aerospace

Rapid PCB

Agriculture

In addition, rapid PCB prototypes are the need for almost every startup that needs to showcase a minimum viable product to investors!

Technotronix Advantage for Rapid Prototype PCB

At Technotronix, we have over 40 years of experience in fabricating, assembling and prototyping rapid PCBs. With state-of-the-art equipment and an experienced team, we are well-poised, not just to provide you with a high-quality product but also a wealth of industry knowledge. When you join hands with us what you are bringing on board is a partner invested in your success. We can provide a comprehensive feedback on your PCB design before getting to the PCB prototype production stage.

Our quick turnaround times are particularly suited for prototypes where you want to test the product early and iron out any flaws. Either way, we do not let quantity come in the way of quality, for we provide both rapid PCB prototypes as well as large production runs.

Our stringent quality checks ensure that you can rest assured that what you will get are high-quality boards. Our capability to fabricate boards as per your bespoke requirements, no matter how complex, adds to our credibility.

The fact that we also offer turnkey board production means that you can benefit from our end-to-end expertise.

All of this at the most cost-effective prices that ensure that your project is extremely competitive!

All you need to do is to get in touch with our team with your bespoke rapid PCB prototyping requirements and see them revert with a custom quote. Design, build, test, got a whole new meaning with our quality rapid PCB prototyping service!

Experience a seamless process, right from placing your order to DFM resolution, a responsive team, quick turnaround times and above all high-quality boards!

Rapid PCB Prototype FAQs

Rapid PCB prototyping is a useful practice that shortens the time required to develop designs and enables you not to face any costly errors.

We manufacture rapid printed circuit boards in our state-of-art manufacturing unit with latest equipment and advanced technology in Anaheim, California, USA.

Some advantages include:
  • Short turnaround times
  • Flexibility in making changes, if any
  • Reduced time to market
  • Ability to test components separately
  • Reduced costs
  • Better final products

A concept with their design needs to be ready first before the PCB design is committed to mass production. This is the prototype stage. Once the OEM has established that the basic prototype boards are working to their satisfaction and any potential errors have been weaned, it is time to move to a standard production run.

Yes, that is one of the advantages that PCB Prototyping offers.

They help provide a proof-of-concept that can, among other things, be showcased to investors

Yes, absolutely. In addition, we also offer prototypes for rigid-flex boards.

Absolutely!

Yes, we take the “rapid” in PCB prototyping very seriously and offer quick turnaround times.

Rest assured that we offer robust customer support, with our team hand holding you, every step of the way. From quick quotes to delivery and after sales, we are there with you.

Totally, we offer the best prices.

While our emphasis is on speed, it is without compromising quality.

Yes, absolutely! From HASL, Immersion Silver, Immersion Gold, Hard Gold, Soft Bondable Gold, ENIG, we offer a wide range. s
contact icon

To get an exact rapid PCB prototype or custom rapid PCB prototyping for your new product, remodeling or for other novelties, you can use Rapid printed circuit board prototype Assembly quote request form or Rapid printed circuit board prototype Fabrication quote request form and submit information. In case you need Rapid printed circuit board prototype fabrication and Rapid printed circuit board prototype assembly both, please submit both forms separately. Alternatively, you can email us BOM and Gerber files on sales@technotronix.us or call us on 714/630-9200 in case any other clarification is required in respect to our Rapid printed circuit board prototype services.
