Rogers PCB Manufacturer

ROGERS PCB

The use of high frequency Rogers PCB material is imperative when it comes to fabricating Rogers PCBs for critical applications that particularly need low signal loss as well as low dielectric loss. Such material is also the need of the hour when signal integrity and impedance matching are of utmost importance.

At Technotronix, we provide Rogers printed circuit boards, one of the well-known names, when it comes to Rogers PCB manufacturing:

  • Dielectrics
  • Laminates
  • Prepregs

Their high-quality materials are especially known for their ability to withstand harsh environmental conditions.

ROGERS PCB FABRICATION CAPABILITIES

We are fully equipped to manufacture eponymous printed circuit boards from material sourced from Rogers that is known for their durability and reliability. We provide high-mix PCBs, high frequency Rogers PCBs, RF Rogers PCBs, SMT Rogers circuit boards, Rogers PCB prototypes, and more. The range of fabricating Rogers PCBs is reliable, efficient, and high performance for any type of specialty applications. The different Rogers PCB products include the following:
Capability Standard
RT/Duriod This is extremely reliable material that comes with the following features:

  • Low electrical loss
  • Low moisture absorption
  • Stable dielectric constant
RO3000 These laminates come in a range of dielectric constants that find extensive application in GPS antennas, Power amplifiers and more.
RO4000 The RO4000 laminates and prepregs are extensively used in instances where controlled impedance is of importance. Their di-electric constants are in the range of 2.55-6.15. These find application in sensors, radars, RFID chips and more.
TMM® The TMM thermoset laminates are known for their excellent mechanical properties and a low thermal coefficient of dielectric constant.

Laminates:
  • Woven Glass Reinforced Modified Epoxy Laminates
  • Woven Glass Reinforced PTFE Antenna Grade Laminates
  • Cross-Plied Woven Glass Reinforced PTFE
  • Woven Glass Reinforced Modified Epoxy IMS
  • Hydrocarbon / Ceramic / Woven Glass UL 94 V-0 Laminates
  • PTFE Ceramic
  • Hydrocarbon / Ceramic / Woven Glass
  • Filled PTFE Composite
  • PTFE Random Glass Fiber
Bonding Materials:
  • Thermoset Thermally & Electrically Conductive Adhesive (TECA) Film
  • Ceramic PTFE Bondply
  • Hydrocarbon / Ceramic / Woven Glass / Prepreg
Metal Claddings:
  • Several models of metal claddings are offered in the following foil type:
  • Rolled
  • Electro Deposited
  • Electro Deposited Reverse Treated
  • Resistive Foil

Benefits of Rogers Printed Circuit Boards:

  • They are well suited to harsh environmental conditions.
  • Rogers PCB shows significantly less moisture absorption as well as improved thermal management.
  • RO4000 material’s thermal co-efficient of expansion is akin to that of copper that offers dimensional stability.
  • Known to display better impedance control.
  • Extremely cost-effective when it comes to Rogers PCB fabrication.
  • Known for lower di-electric loss, lower signal loss, as well as low cross-over.

Application of Rogers PCB

Because of the many advantages that it offers, Rogers PCB finds application in a wide variety of industries, many of them mission critical. Some of the applications include:

Rogers PCB

RFID tags

Rogers Printed Circuit Boards

Broadcast Satellites

Rogers Material PCB

Power amplifiers

Rogers PCB Prototype

Mobile applications

Rogers PCBs

Microwave equipment

Rogers Material PCBs

Radars and sensors

WHY US?

When you need highly reliable Rogers printed circuit board assemblies, you can count on Technotronix. You can rest assured that we will utilize the high-quality Rogers material and combine it with our technical expertise in creating high quality PCBs. Our Rogers PCB manufacturers will be happy to receive your bespoke requirements and ensure that your concept is brought to life.

FAQs

These are eponymous PCBs manufactured from material sourced from Rogers Corporation that is known for their durability and reliability.

They not only support the making of next generation designs but also contribute to lower dielectric loss and low electrical signal loss.

Rogers PCBs, as opposed to FR-4, are well suited for high frequency applications.

Roger PCB is extremely suited for use in high moisture areas on account of their low moisture absorption capability.

We source a wide range of laminates, bonding materials, and metal claddings, among other materials.

Yes, we are cognizant of the fact that time-to-market is important, and therefore we have an unstinting focus on delivery times.

Yes, on account of low outgassing they are chosen for space applications.

Some of the foil types that are commonly used include rolled, electro deposited, electro deposited reverse treated and resistive foil.
contact icon

Do you have any Rogers printed circuit boards requirements? Request a free Rogers PCB fabrication quote. Alternatively, email BoM, Gerber files, and other required details at [email protected] or call us 714/630-9200.
