Standard PCB

We are a full-service provider of standard printed circuit boards and custom printed circuit boards. The standard printed circuit boards are the widely used solution for any kind of PCB needs. Our U.S. based manufacturing facilities and the latest PCB manufacturing equipment allow us to provide fast and flexible turn times to meet our customer’s tight project deadlines.

When it comes to standard PCBs, there is a range of common or standard PCB thicknesses. These include 0.031 in (0.78mm), 0.062 in (1.57mm) and 0.093 in (2.36mm). When determining the PCB thickness, of course, there a number of design and manufacturing factors to consider. Some of these include:

Factors that Impact Standard PCB Thickness

  • Board Material
  • Thickness of Copper
  • Number of layers
  • Type of signals
  • Type of vias
  • The overall environment of operation
  • Depanelization method

While most designers target standard board thickness values, boards also need to be designed to target standard panel sizes. The most common standard panel sizes are:

  • 18" × 24"
  • 18" × 12"
  • 9" × 24"
  • 9" × 12"

As a thumb rule, standard PCB services need to be undertaken once you are ready to move from the prototype to the mass production stage.

At Technotronix, we offer standard PCB services including a wide range of substrate material including:

  • Aluminum
  • FR4
  • Rogers, and more.

Standard PCB services come with tighter production tolerances.

Capabilities of Standard Printed Circuit Boards

Our capabilities in standard PCBs include:
Feature Capability
Quality Grade Standard IPC 2
Number of Layers 1 - 32layers
Order Quantity 1pc - 10,000,000 pcs
Material FR-4 Standard Tg 150°C, FR4-High Tg 170°C, FR4-High-Tg 180°C, FR4-Halogen-free, FR4-Halogen-free & High-Tg
Min Tracing/Spacing 3mil/3mil
Solder Mask Sides As per the file
Solder Mask Color Green, White, Blue, Black, Red, Yellow
Silkscreen Sides As per the file
Silkscreen Color White, Blue, Black, Red, Yellow
Surface Finish HASL - Hot Air Solder Leveling
Lead Free HASL - RoHS
ENIG - Electroless Nickle/Immersion Gold - RoHS
ENEPIG - Electroless Nickel Electroless Palladium Immersion Gold - RoHS
Immersion Silver - RoHS
Immersion Tin - RoHS
OSP -Organic Solderability Preservatives - RoHS
Min Annular Ring 3mil
Min Drilling Hole Diameter 6mil, 4mil-laser drill
Min Width of Cutout (NPTH) 0.8mm
NPTH Hole Size Tolerance ±.002" (±0.05mm)
Min Width of Slot Hole (PTH) 0.6mm
PTH Hole Size Tolerance ±.003" (±0.08mm) - ±4mil
Surface/Hole Plating Thickness 20μm - 30μm
SM Tolerance (LPI) .003" (0.075mm)
Aspect Ratio 1.10 (hole size: board thickness)
Test 10V - 250V, flying probe or testing fixture
Impedance tolerance ±5% - ±10%
SMD Pitch 0.2mm(8mil)
BGA Pitch 0.2mm(8mil)

Benefits of Standard PCBs

Standard PCBs come in handy once the prototype boards have been made and your design has been fully tested. Post that placing a bulk order for standard PCBs can go a long way in saving costs. Standard PCBs can be made to comply with IPC 2 with strict internal quality assurance testing so as to ensure that they are fully reliable.

Application of Standard Printed Circuit Boards

Standard PCBs find wide application in high volume production runs once the prototype and the design stage is over. With the capability to print advanced circuit boards in large dimensions, they work well even for large designs. With design for manufacturing analysis of all standard PCBs, it is ascertained that the PCB design will turn out as expected.

The top applications for standard printed circuit boards include:

Standard Printed Circuit Board

Consumer Electronics

Standard Circuit Boards

LEDs

Standard PCBS

Automotive Components

Standard Printed Circuit Board Assembly

Telecommunications Equipment

Standard Printed Circuit Board Assemblies

Safety and security equipment

Standard Circuit Board

Medical Devices

Standard PCB Boards

Digital Components

Standard PCB Board

Manufacturing Equipment

Technotronix Advantage as a Standard PCB Manufacturer

At Technotronix, we have more than 4 decades of experience in fabricating and assembling a wide variety of PCBs. Our state-of-the-art equipment and team of experts are well-equipped to handle your requirements.

We work with standard PCB sizes for rigid boards as well as with rigid-flex and flex assemblies while minimizing costs and cycle times.

We are extremely committed to offering quick turnaround times that help you go-to-market early. The fact that we can offer large quantities when it comes to standard PCBs, gives us an edge. You can rest assured that with our strict compliance to quality as well as design for manufacturing tests, the standard PCBs are extremely reliable.

All you need to do is to get in touch with our team and share your requirements. Our experienced team will share a quote, send us your go ahead and receive your PCBs with quick turnaround time.

If you need something other than the standard PCB sizes for your stack up, or require boards with custom shapes, you can rely on us for that too. We can offer a variety of core and pre-preg laminate thicknesses for advanced custom stack-ups.

All of this at the most cost-effective prices that ensure that your PCB manufacturing project is extremely competitive!

Standard PCBs FAQs

Standard PCBs conform to a standard thickness. Largely these include 0.031in (0.78mm), 0.062in (1.57mm) and 0.093in (2.36mm).

Once the prototype design has been tested, standard PCBs offer a cost-effective and reliable option.

There are several factors including board material, thickness of copper, number of layers, types of vias, depanelization methods and more that determine the thickness of the PCB.

Standard PCBS come with tight production tolerances.

Yes, we cater to a wide range of surface finishes.

Yes, whether you need single sided, double sided or multilayered standard printed circuit boards, we have you covered.

We pride ourselves on offering quick turnaround times. Get in touch with us with your requirements and you will get quick turn standard PCBs.

There is no exaggeration when we say that we offer robust customer support with our team hand holding you, every step of the way.

We have over 4 decades of experience in dealing with different varieties of PCBs. Our state-of-the-art equipment and team of experts offer significant advantages.

We have robust quality check procedures in place. Above everything, a large portfolio of satisfied clients stands as the biggest testimony to our success.

Absolutely. We offer cost-effective prices that make your project viable.

Please feel free to request a quick standard PCB quote for any kind of requirements that you may have. Alternately, you can also get in touch with us at 714/630-9200, 714/630-9207, or write in to us at [email protected].
